Manufacturing Facilities
CNC Routers
CNC Router is an essential device for making Thermocol Patterns, Wooden Patterns and Core Boxes for customer’s requirement. Here you can see our capabilities for CNC Routers:
Machine – CNC Router
Model – IM-4RX 1530
Machine Make – Incredible
Bad Capacity :
X(mm) – 1200
Y(mm) – 2400
Z(mm) – 350
No. of Machines – 1
Machine – CNC Router
Model – RT-1325
Machine Make – Raghav tecnology
Bad Capacity :
X(mm) – 1200
Y(mm) – 2400
Z(mm) – 350
No. of Machines – 1
Machine – CNC Router
Model – RTP-1530
Machine Make – Raghav tecnology
Bad Capacity :
X(mm) – 2000
Y(mm) – 2000
Z(mm) – 700
No. of Machines – 1
Casting Foundry
For making different kind of Aluminum Dies we need different – different Graded Aluminum Blocks (As Per Customer’s Requirement) which has different sizes. So, for each and every inquiry we have to cast that block from Aluminum Sand Casting foundry. For bigger Castings we have to do casting from Thermocol Patterns, too.
Capacity of Crucible Furnace:
- 1000 kg
- 500 kg
- 400 kg
VMC Machines
Machine – VMC 850 NVU
Model – 850
Machine Make – Jyoti CNC
Bad Capacity :
X(mm) – 800
Y(mm) – 500
Z(mm) – 450
No. of Machines – 2
Machine – VMC
Model – CVM 1060
Machine Make – Cosmos
Bad Capacity :
X(mm) – 1250
Y(mm) – 610
Z(mm) – 600
No. of Machines – 2
Machine – VMC
Model – CVM 640
Machine Make – Cosmos
Bad Capacity :
X(mm) – 650
Y(mm) – 450
Z(mm) – 500
No. of Machines – 1
Machine – VMC 850 NVU
Model – CVM 800
Machine Make – Cosmos
Bad Capacity :
X(mm) – 800
Y(mm) – 500
Z(mm) – 500
No. of Machines – 1
Machine – VMC
Model – BMV AGNI 45 ++
Machine Make – BFW
Bad Capacity :
X(mm) – 600
Y(mm) – 450
Z(mm) – 500
No. of Machines – 1
Machine – VMC
Model – BMV 60+
Machine Make – BFW
Bad Capacity :
X(mm) – 1050
Y(mm) – 610
Z(mm) – 610
No. of Machines – 1
Fitting Shop
20×20 sq.Feet Area is dedicatedly allotted for Any Pattern and Die’s Fitting, Assembly and Finishing Purpose. Fitting shop is equipped with Drilling Machines, Lathe Machines, Grinders, Assembly Tools, Finishing Tools, Paint’s equipments, etc.
Pentograph Machines
As we are believing in Quality, so we never compromise in even lettering on Dies and Patterns. So, we always provide Brass Holograms for lettering Portions. For that we have following machines:
Machine – Pentograph
Model – Perfect-600
Machine Make -Perfect
Bad Capacity :
X(mm) – 600
Y(mm) – 600
Z(mm) – 150
No. of Machines – 3
